PSGS-2210F(130W)
Product Overview
PSGS-2210F L2+ managed GbE PoE+ switch is the next-generation Ethernet Switches offering full suite of L2 features, additional 1GbE uplink connections, better PoE functionality and usability, including advanced L3 features such as Static Route.
PSGS-2210F delivers 8 (10M/100M/1G) RJ45 with 8 PoE+ (Support 802.3at/af, and total up to 130W) ports, 2 1G SFP ports and RJ45 Console port.
PSGS-2210F provides high HW performance and environment flexibility for SMBs and Enterprises.
| Key Features | Customer Benefits |
|---|---|
| L2+ Managed Features | Easier manageability, robust security and QoS |
| DHCP Server | Assigns IP addresses to DHCP clients |
| IPv4/IPv6 Management | Supports management across IPv4 and IPv6 networks |
| PoE Port Configuration and Scheduling | Configure and schedule PoE power per port |
| 802.3at PoE+ | High power PoE plus standard for powered devices |
| Green/Power Saving | IEEE 802.3az Energy Efficient Ethernet helps lower power consumption |
Product Specification
| MODEL NAME | PSGS-2210F |
|---|---|
| Product Description | 10 ports GbE L2+ Managed PoE+ Switch |
Port Configuration
10M/100M/1G RJ45 Port | 8 | |
100M/1G/2.5G RJ45 Port | -- | |
100M/1G/10G RJ45 Port | -- | |
100M/1G/2.5G/5G/10G RJ45 Port | -- | |
100M/1G SFP Port | 2 | |
GbE RJ45/SFP Combo Port | -- | |
1G/2.5G SFP Port | -- | |
1G/10G SFP+ Port | -- | |
SFP28/QSFP+ Combo Port | -- | |
1G/10G/25G SFP28 Port | -- | |
QSFP+ (40G) | -- | |
SFP56 (50G) | -- | |
USB | -- | |
Console Port | RJ45 | |
OOB Port | -- | |
Total Ports | 10 |
|
PoE Function
IEEE802.3at (PoE+ 30W) | | |
IEEE802.3af (PoE 15.4W) | | |
UPoE(60W) | -- | |
IEEE802.3bt (PoE++ 90W) | -- | |
PoE Port | 8 | |
Available PoE Power | 130W |
|
HW Performance
Switching Bandwidth | 20 Gbps | |
Forwarding Performance | 14.88Mpps | |
MAC Address | 8K | |
Jumbo Frames | 9216 Bytes |
|
Environmental Specification
Operating Temperature | 0°C to 40°C | |
Operating Humidity | 10 to 90% RH | |
Storage Temperature | -40 to 70°C | |
Storage Humidity | 5 to 90% RH |
|
Mechanical Specification
Dimensions (H) x (W) x (D) mm | 44 x 265 x 183 | |
Weight | 1.4 Kg | |
FAN Less | |
|
Power Source
AC Input | 100V-240V | |
DC Input | -- | |
Dual Input | -- |
|
Certifications
EN61000-4-5 (for RJ45 Port, Surge 6KV) | -- | |
Certifications | CE/FCC Class A Others by Request |
|
L2 Switching
Spanning Tree |
IEEE802.1D (STP) | |
IEEE802.1W (RSTP) | | |
IEEE802.1S (MSTP) | | |
VLAN |
802.1Q VLAN | |
Port-Based | | |
VLAN Entries | 4K | |
Private VLAN | | |
Voice VLAN | | |
Guest VLAN | | |
Q-in-Q | | |
802.1v Protocol VLAN | | |
MAC-Based VLAN | | |
IP Subnet-Based VLAN | | |
IEEE 802.3ad LACP |
Dynamic Trunk | |
Static Trunk | | |
GARP/GVRP | -- | |
IGMP Snooping | | |
MLD Snooping | | |
Multicast VLAN Registration (MVR) | |
|
L3 Features
Static Route | | |
DHCP Server | | |
Dynamic Routing | -- | |
RIP v1/v2 | -- | |
OSPF v2/v3 | -- |
|
QoS Features
Class of Service |
Port Based | |
802.1p | | |
DSCP | | |
TCP/UDP Port | -- | |
Rate Limiting |
Ingress | |
Egress | -- | |
Priority Queue Scheduling |
WRR | |
Stri Priority | | |
Hardware Queues | 8 |
|
Security
ACLs |
L2/L3/L4 | |
IPv6 Support | -- | |
Port Security (MAC-based) | | |
IP Source Guard | | |
Storm Control | | |
RADIUS Authentication 802.1x | | |
TACACS+ Authentication | | |
HTTPs and SSL (Secured Web) | | |
BPDU Guard | | |
STP Root Guard | | |
DHCP Snooping | | |
Loop Protection | |
|
Management
DHCP |
Client | |
Relay | | |
Option 66 | | |
Option 67 | | |
Option 82 | | |
Event/Error Log |
Syslog | |
SMTP (RFC821) | | |
Management Access Filtering |
SNMP | |
Web UI | | |
Telnet | | |
SSH | | |
PoE Management |
Scheduling | |
Auto-Checking | | |
Power Delay | | |
Soft-Reboot PoE Non-stop | | |
SNMP (v1, v2c, v3) | | |
RMON (1,2,3 & 9 Groups) | | |
Software Upgrade | | |
Configuration Export/Import | | |
Port Mirroring | | |
LLDP (IEEE802.1AB) | | |
LLDP-MED (IEEE802.1AB) | | |
CDP Aware | | |
sFlow | -- | |
IPv6 Management | | |
NTP | | |
First Time Wizard | |
|
PSGS-2210F L2+ Managed GbE PoE+ Switch
PSGS-2210F L2+ managed GbE PoE+ switch is the next-generation Ethernet Switches offering full suite of L2 features, additional 1GbE uplink connections, better PoE functionality and usability, including advanced L3 features such as Static Route.
PSGS-2210F delivers 8 (10M/100M/1G) RJ45 with 8 PoE+ (Support 802.3at/af, and total up to 130W) ports, 2 1G SFP ports and RJ45 Console port.
PSGS-2210F provides high HW performance and environment flexibility for SMBs and Enterprises.
Key Features
- L2+ Managed features provide easier manageability, robust security and QoS.
- DHCP Server
- IPv4/IPv6 Management
- PoE Port configuration and scheduling
- 802.3at high power PoE plus standard
- IEEE 802.3az EEE Energy Efficient Ethernet standard for green Ethernet
Benefits
The switch delivers advanced functionality in L2+ managed switch including Layer 3 static route and DHCP server. It also has comprehensive security features such as IP source guard and ACL to guard your network from unauthorized access.
It helps users to build on the market-leading price/performance with L2+ Managed GbE PoE switch, and provide secure, reliable and ease of use for enterprise/SMB deployments.
It is designed to help customers to reduce power consumption and lower the TCO by Energy Efficient Ethernet (IEEE 802.3az) features. It can be used for customers to build a green Ethernet networking environment.
The model includes PoE+ options to power IP devices with power-saving features like Power scheduling and PoE configuration.
Specifications
Port Configuration
| Total Ports | RJ45 (10M/100M/1G) | Combo (100M/1G) | Uplinks | Console |
|---|---|---|---|---|
| 10 | 8 | — | 2 1G SFP | RJ45 |
Hardware Performance
| Forwarding Capacity (Mpps) | Switching Capacity (Gbps) | Mac Table (K) | Jumbo Frames (Bytes) |
|---|---|---|---|
| 14.88 | 20 | 8 | 10000 |
Environmental Range
| Operating Temperature | Storage Temperature | Operating Humidity | Altitude | |||
|---|---|---|---|---|---|---|
| Fahrenheit | Centigrade | Fahrenheit | Centigrade | Up to 90%, Non-condensing | Feet | Meters |
| 32 to 104 | 0 to 40 | -40 to 158 | -40 to 70 | Up to 90%, Non-condensing | < 10000 | <3000 |
Dimension, Weights, Mounting
| Dimension (WxHxD) | Weight | Mounting Type | ||
|---|---|---|---|---|
| Millimeter | Inches | Kilograms | Pounds | |
| 265x44x183 | 10.4 x1.7 x7.2 | TBD | TBD | Desktop, Rack |
Voltage and Frequency
| AC Input Voltage and Frequency | |
|---|---|
| Voltage | Frequency |
| 100-240 VAC | 50~60 Hz |
PoE Power Capacity
| Available PoE Power | Number of Ports That Support PoE(15.4W) and PoE+(30.0W) |
|---|---|
| 130W | Each of port 1 – 8 support PoE/ PoE+ within available PoE Power |
Certifications
| Electromagnetic Emissions (EMC) |
|---|
| CE, FCC Part 15 Class A, Others by Request |
Software Features
| Layer 2 Switching | |
|---|---|
| Spanning Tree Protocol (STP) |
|
| Trunking | Link Aggregation Control Protocol (LACP) IEEE 802.3ad Up to 4 ports per group |
| VLAN | Supports up to 4K VLANs simultaneously (out of 4096 VLAN IDs), Port-based VLAN, 802.1Q tag-based VLAN, MAC-based VLAN, Guest VLAN, Private VLAN, Voice VLAN, 802.1v Protocol VLAN, IP Subnet-Based VLAN, Q-in-Q |
| IGMP v1/v2/v3 Snooping | IGMP limits bandwidth-intensive multicast traffic to only the requesters. Supports 512 multicast groups |
| MLD v1/v2 Snooping | Delivers IPv6 multicast packets only to the required receivers |
| L3 Features | |
| DHCP Server | Support DHCP server to assign IP to DHCP clients |
| Static Route | IPv4 Unicast: Static routing IPv6 Unicast: Static routing |
| Security | |
| Secure Shell (SSH) | SSH secures Telnet traffic in or out of the switch, SSH v1 and v2 are supported |
| Secure Sockets Layer (SSL) | SSL encrypts the http traffic, allowing advanced secure access to the browser-based management GUI in the switch |
| IEEE 802.1X | IEEE802.1X: RADIUS authentication, authorization and accounting, MD5 hash, guest VLAN, single/multiple host mode and single/multiple sessions Dynamic VLAN assignment |
| Port Security | Locks MAC addresses to ports, and limits the number of learned MAC address |
| TACACS+ | Supports TACACS+ authentication. |
| Storm Control | Prevents traffic on a LAN from being disrupted by a broadcast, multicast, or unicast storm on a port |
| ACLs | Supports up to 256 entries. Drop or rate limitation based on source and destination MAC, VLAN ID or IP address, port |
| IP Source guard | Prevents illegal IP address from accessing to specific port in the switch |
| DHCP Snooping | A feature acts as a firewall between untrusted hosts and trusted DHCP servers |
| Loop Protection | To prevent unknown unicast, broadcast and multicast loops in Layer 2 switching configurations. |
| DHCP Client | Support DHCP server to assign IP to DHCP clients |
| DHCP Relay (option 66,option 67,option 82) | Relay of DHCP traffic to DHCP server in different VLAN. Works with DHCP Option 82 |
| Quality of Service | |
| Hardware Queue | Supports 8 hardware queues |
| Scheduling | Strict priority and weighted round-robin (WRR) Queue assignment based on DSCP and class of service |
| Classification | Port based 802.1p VLAN priority based IPv4/IPv6 precedence / DSCP based |
| Rate Limiting | Ingress policer Egress shaping and rate control |
| Management | |
| Remote Monitoring (RMON) | Embedded RMON agent supports RMON groups 1,2,3,9 for enhanced traffic management, monitoring and analysis |
| Port Mirroring | Traffic on a port can be mirrored to another port for analysis with a network analyzer or RMON probe. Up to N-1 ports can be mirrored to single destination port. A single session is supported. |
| Web GUI Interface | Built-in switch configuration utility for browser-based device configuration |
| CLI/ Telnet | For users to configure/manage switches in command line modes |
| Dual Image | Independent primary and secondary images for backup while upgrading |
| SNMP | SNMP version1, 2c and 3 with support for traps, and SNMP version 3 user-based security model (USM) |
| Firmware Upgrade | Web browser upgrade (HTTP/ HTTPs) and TFTP, SFTP, and SCP Upgrade through console port as well |
| Syslog | Support syslog function |
| SMTP | Support SMTP (RFC821) |
| IEEE 802.1ab (LLDP) | Used by network devices for advertising their identities, capabilities, and neighbors on an IEEE 802ab local area network Support LLDP-MED extensions |
| CDP Aware | The CDP operation is restricted to decoding incoming CDP frames. CDP frames are only decoded if LLDP on the port is enabled |
| NTP | Network Time Protocol (NTP) is a networking protocol for clock synchronization between computer systems over packet-switched |
| Other Management | IPv6 Management |
| Power over Ethernet (PoE) | |
| Port Configuration | Supports per port PoE configuration function |
| PoE Scheduling | Supports per port PoE scheduling to turn on/off the PoE devices (PDs). |
| Auto-checking | Check the link status of PDs. Reboot PDs if there is no responses. |
| Power Delay | The switch provides power to the PDs based on delay time when PoE switch boots up, in order to protect switch from misuse of the PDs |
| Soft-Reboot PoE Non-stop | The switch will keep providing power to the PDs while during soft-reboot. |
PSGS-2200 Series L2+ Managed GbE PoE+ Switches
The PSGS-2200 series L2+ managed GbE PoE+ switches are the next-generation Ethernet Switches offering powerful L2 features with better PoE functionality and usability. That delivers the cost-effectively business and transports Ethernet services via fiber or copper connections.
The PSGS-2200 series consists of 3 PoE+ models which are PSGS-2210F, PSGS-2226XAL and PSGS-2228XBF. The series offer users with various options of port combinations and PoE+ budget, in order to meet different requirements in various applications.
Key Features
- L2+ Managed features provide easier manageability, robust security and QoS
- DHCP Server
- IPv4/IPv6 Management
- PoE Port configuration and scheduling
- 802.3at high power over plus standard
- IEEE 802.3az EEE Energy Efficient Ethernet standard for green Ethernet
Benefits
The switch delivers advanced functionality in L2+ managed switch including Layer 3 static route and DHCP server. It also has comprehensive security features such as IP source guard and ACL to guard your network from unauthorized access.
It helps users to build on the market-leading price/performance with L2+ Managed GbE PoE+ switch, and provide secure, reliable and ease of use for enterprise/SMB deployments.
It is designed to help customers to reduce power consumption and lower the TCO by Energy Efficient Ethernet (IEEE 802.3az) features. It can be used for customers to build a green Ethernet networking environment.
The model includes PoE+ options to power IP devices with power-saving features like Power scheduling and PoE configuration.
Specifications
Port Configuration
| Model Name | Total Ports | RJ45 10M/100M/1G | Uplinks 100M/1G | Console | Available PoE Power |
|---|---|---|---|---|---|
| PSGS-2210F | 10 | 8 | 2 1G SFP | RJ45 | 130W |
| PSGS-2226XAL | 26 | 24 | 2 10G SFP+ | RJ45 | 185W |
| PSGS-2228XBF | 28 | 24 | 4 10G SFP+ | RJ45 | 380W |
Hardware Performance
| Model Name | Forwarding Capacity (Mpps) | Switching Capacity (Gbps) | Mac Table(K) | Jumbo Frames(Bytes) |
|---|---|---|---|---|
| PSGS-2210F | 14.88 | 20 | 8 | 10K |
| PSGS-2226XAL | 65.47 | 88 | 16 | 10K |
| PSGS-2228XBF | 95.232 | 128 | 16 | 12K |
Environmental Range
| Operating Temperature | Storage Temperature | Operating Humidity | Altitude | |||
|---|---|---|---|---|---|---|
| Fahrenheit | Centigrade | Fahrenheit | Centigrade | Up to 90%, Non-condensing | Feet | Meters |
| 32 to 104 | 0 to 40 | -40 to 158 | -40 to 70 | Up to 90%, Non-condensing | < 10000 | <3000 |
Dimension, Weights, Mounting
| Model Name | Dimension (WxHxD) | Weight | Mounting Type | ||
|---|---|---|---|---|---|
| Millimeter | Inches | Kilograms | Pounds | ||
| PSGS-2210F | 265x44x183 | 10.4x1.7x7.2 | 1.4kg | 3.09lbs | Desktop, Rack |
| PSGS-2226XAL | 441x44x270 | 17.3x1.7x10.6 | TBD | TBD | Desktop, Rack |
| PSGS-2228XBF | 441x44x270 | 17.3x1.7x10.6 | TBD | TBD | Desktop, Rack |
Voltage and Frequency
| AC Input Voltage and Frequency | |
|---|---|
| Voltage | 100-240 VAC |
| Frequency | 50~60 Hz |
PoE Power Capacity
| Model Name | Available PoE Power | Number of Ports That Support PoE(15.4W), PoE+(30.0W) |
|---|---|---|
| PSGS-2210F | 130W | Each of port 1 - 8 support PoE/ PoE+ within available PoE Power |
| PSGS-2226XAL | 185W | Each of port 1 - 24 support PoE/ PoE+ within available PoE Power |
| PSGS-2228XBF | 380W | Each of port 1 - 24 support PoE/ PoE+ within available PoE Power |
Certifications
| Electromagnetic Emissions (EMC) |
|---|
| CE, FCC Part 15 Class A, Others by Request |
Software Features
| Layer 2 Switching | |
|---|---|
| Spanning Tree Protocol (STP) |
|
| Trunking | Link Aggregation Control Protocol (LACP) IEEE 802.3ad Up to 4 ports per group |
| VLAN | Supports up to 4K VLANs simultaneously (out of 4096 VLAN IDs) Port-based VLAN 802.1Q tag-based VLAN MAC-based VLAN Guest VLAN Private VLAN Voice VLAN 802.1v Protocol VLAN IP Subnet-Based VLAN Q-in-Q |
| IGMP v1/v2/v3 Snooping | IGMP limits bandwidth-intensive multicast traffic to only the requesters. Supports 512 multicast groups |
| MLD v1/v2 Snooping | Delivers IPv6 multicast packets only to the required receivers |
| L3 Features | |
| DHCP Server | Support DHCP server to assign IP to DHCP clients |
| Static Route | IPv4 Unicast: Static routing IPv6 Unicast: Static routing |
| Security | |
| Secure Shell (SSH) | SSH secures Telnet traffic in or out of the switch, SSH v1 and v2 are supported |
| Secure Sockets Layer (SSL) | SSL encrypts the http traffic, allowing advanced secure access to the browser-based management GUI in the switch |
| IEEE 802.1X | IEEE802.1X: RADIUS authentication, authorization and accounting, MD5 hash, guest VLAN, single/multiple host mode and single/multiple sessions Dynamic VLAN assignment |
| Port Security | Locks MAC addresses to ports, and limits the number of learned MAC address |
| TACACS+ | Supports TACACS+ authentication. |
| Storm Control | Prevents traffic on a LAN from being disrupted by a broadcast, multicast, or unicast storm on a port |
| ACLs | Supports up to 256 entries. Drop or rate limitation based on source and destination MAC, VLAN ID or IP address, port |
| IP Source guard | Prevents illegal IP address from accessing to specific port in the switch |
| DHCP Snooping | A feature acts as a firewall between untrusted hosts and trusted DHCP servers |
| Loop Protection | To prevent unknown unicast, broadcast and multicast loops in Layer 2 switching configurations. |
| DHCP Client | Support DHCP server to assign IP to DHCP clients |
| DHCP Relay (option 66,option 67,option 82) | Relay of DHCP traffic to DHCP server in different VLAN. Works with DHCP Option 82 |
| Quality of Service | |
| Hardware Queue | Supports 8 hardware queues |
| Scheduling | Strict priority and weighted round-robin (WRR) Queue assignment based on DSCP and class of service |
| Classification | Port based 802.1p VLAN priority based IPv4/IPv6 precedence / DSCP based |
| Rate Limiting | Ingress policer Egress shaping and rate control |
| Management | |
| Remote Monitoring (RMON) | Embedded RMON agent supports RMON groups 1,2,3,9 (history, statistics, alarms, and events) for enhanced traffic management, monitoring and analysis |
| Port Mirroring | Traffic on a port can be mirrored to another port for analysis with a network analyzer or RMON probe. Up to N-1 ports can be mirrored to single destination port. A single session is supported. |
| Web GUI Interface | Built-in switch configuration utility for browser-based device configuration |
| CLI/ Telnet | For users to configure/manage switches in command line modes |
| Dual Image | Independent primary and secondary images for backup while upgrading |
| SNMP | SNMP version1, 2c and 3 with support for traps, and SNMP version 3 user-based security model (USM) |
| Firmware Upgrade | Web browser upgrade (HTTP/ HTTPs) and TFTP, SFTP, and SCP Upgrade through console port as well |
| Syslog | Support syslog function |
| SMTP | Support SMTP (RFC821) |
| IEEE 802.1ab (LLDP) | Used by network devices for advertising their identities, capabilities, and neighbors on an IEEE 802ab local area network Support LLDP-MED extensions |
| CDP Aware | The CDP operation is restricted to decoding incoming CDP frames. CDP frames are only decoded if LLDP on the port is enabled |
| NTP | Network Time Protocol (NTP) is a networking protocol for clock synchronization between computer systems over packet-switched |
| Other Management | IPv6 Management |
| Power over Ethernet (PoE) | |
| Port Configuration | Supports per port PoE configuration function |
| PoE Scheduling | Supports per port PoE scheduling to turn on/off the PoE devices (PDs). |
| Auto-checking | Check the link status of PDs. Reboot PDs if there is no responses. |
| Power Delay | The switch provides power to the PDs based on delay time when PoE switch boots up, in order to protect switch from misuse of the PDs |
| Soft-Reboot PoE Non-stop | The switch will keep providing power to the PDs while during soft-reboot. |
ODM Ethernet Switches with Customizable Hardware Features
Logo Customization
Front-bezel logo customization.
Mylar Customization
Front-bezel Label / Mylar customization.
Combination Port Customization
Combination of RJ-45/SFP/SFP+ ports counts.
PoE Power Customization
PoE / PoE+ / PoE++ Power Customization.
CPU Customization (PoE NVR)
Intel / AMD CPU
HDD / SSD tray Customization (PoE NVR)
2/3/4/6 HDD/SSD tray Customization.
Switch Case Size Customization
Small Form Factor Case Size.
ITU-T Customization
ITU-T G.8032 ERPS.
Temperature Customization
Wide Temperature Support (-20℃~60℃)
FAN Customization
Inteligent FAN Speed Control/Fan-less Design.
GPU Customization (PoE NVR)
Add stand-alone Low Profile graphics card
OS Customization (PoE NVR)
Win Server / Win 10 / Ubuntu / Linux…
ODM Ethernet Switches with Customizable Software Features
Tailored Software Customization for UI and Features
Our expert R&D team offers comprehensive software customization, allowing you to personalize the user interface (UI) to match your brand identity and improve user experience. Additionally, we work closely with you to develop and implement the specific features you need, ensuring that our solutions fully align with your business goals. Whether it's enhancing existing functionalities or adding entirely new capabilities, we ensure seamless integration and optimal performance.
AI-Enhanced Switches with Advanced Configuration Support
Upgrade your Ethernet switches to AI-powered switches with the latest AI assistant integration. Our AI assistant simplifies switch configuration, guiding users step-by-step through setup and management tasks, reducing time and complexity. Additionally, our switches support cutting-edge AI SUPPORT features, enabling real-time diagnostics, automated troubleshooting, and intelligent performance optimization. With these advanced AI functionalities, your switches will evolve into smart, AI-driven network solutions, providing unparalleled efficiency and scalability for modern networking environments.
Seamless Third-Party API Integration for Enhanced Product Synergy
Our solutions offer full support for integrating third-party APIs, enabling deep and seamless integration with your existing systems. Whether you need to connect to external platforms, enhance data flow, or unify multiple systems, our tailored approach ensures smooth compatibility and optimized performance. By combining our advanced networking technology with your current infrastructure, we empower your products with greater flexibility, functionality, and interoperability, driving efficiency and reducing operational complexity.
Device Management System
When we embed Device Management System to the switch, a new era of possibilities begins. One where IT administrators are empowered with system of easy-to-use, and where maintenance is effortless and troubleshooting works in a moment.
One UI & iPush enable your business to operate switches in ways never before possible.
